Pure Class-AVacuum TubePowerAmplifier

The Design ofDoubleEavesand Chinese Hipped Roof

TTT Self-developed Power Transformer(PT)

ManualScaffolding andWelding

TTT Optimizedthe Design ofCircuit

Bluetooth 5.0 Wireless Connection

Professional DAC Decoding

Power on Delay for30Seconds

Professional HiFi Terminal

Japanese ALPS Potentiometer

Model: TrePower1

Input Voltage: 220V 3.15A

Rated Output: 9W+9W

Frequency Response: 15Hz~35KHz(-1.5dB)

THD: 1%(1KHz)

SNR: 90dB

Input Sensitivity: 450mV

Input Impedance: 100KΩ

Power Consumption: 155W

Vacuum Tubes: 6N2*2 6P1*6

Load Impedance: 8Ω

Bluetooth: CSR aptX 5.0

Size: 350*272*199mm

Material: Aluminium Alloy

Weight: 14kg

Instruction Manual

The function is to convert weak electroacoustic signals into powerful power energy (amplify voltage and current), and its purpose is to control the speaker to complete the final work of converting electrical energy into sound energy.
Its control ability is directly related to the sound quality, and to some extent dominates whether the entire system can provide good sound quality output.

Warm Sound, Internal Light
Ideal linearity and no crossover distortion, which is the design of pure Class-Avacuum tube power amplifier over the top.

The Design of Double Eaves and Chinese Hipped Roof

This design inspiration comes from Chinese traditional architecture of double eaves and hipped roof.

The electroplated protective cover is like a roof with double eaves, and the whole product is located in front of us like a palace, which is elegant and modern.

Beauty, the Original Point of Sound

Different from the ordinary spliced fuselage, TrePower1’s main body is formed by CNC of a whole aluminum ingot, and then drawn, oxidized and colored.

Give up the boring design of vacuum tube power amplifier, and the beauty of products is the first step to attract people's enjoyment on music.

Surpass Others in the Vacuum Tube Power Amplifier’s Internal

Hidden under the "eaves" are 8 vacuum tubes of Aurora 6*6P1+2*6N2, which is the critical point for the vacuum tube power amplifier. 6P1 is responsible for power amplification, 6N2 is responsible for signal inversion and drive amplification, and ceramic and gold-coated tube socket ensures stable output.

The Priority of Vacuum Tube Power Amplifier

Manual Scaffolding and Welding

Handcrafting is an inherent procedure in TRETTITRE, which exists just like genes, and TrePower1 is no exception.

 The core part is welded by manual scaffolding, which avoids signal and noise interference and enhances the conductivity of the circuit compared with printed circuit. Orderly wiring and excellent welders ensure the consistency and stability of the factory standards of each product.

©TTT Self-developed Power Transformer (PT)

©TTT Optimized the Design of Circuit

SHOP NOW
Bluetooth 5.0 Wireless Connection

It can be connected to mobile phones or music devices that support Bluetooth, support Qualcomm CSR aptX Bluetooth 5.0 connection technology, and cooperate with Texas Instruments’professional DAC decoding chip to transmit high-fidelity audio quickly and stably.

Professional DAC Decoding

Power on Delay for 30 Seconds

Start-up with silent mode and time-delay, so as to improve the service life of vacuum tube and the safety of capacitor.

Match T4 Speaker Show HiFi Fashion

The 4-inch HiFi bookshelf speaker matched with TrePower1 to attract people to enjoy the lingering sound and aftertaste again and again.
